OMNI PRO: Industrial Large-Format 3D Printing

Name: Omni PRO Large-Format Industrial 3D Printer — Freeform Fabrication UK
Brand: Freeform Fabrication UK
Availability: OutOfStock

£0.00

sold out

High-Temperature Engineering and Precision Manufacturing at Scale

The Omni PRO is a professional, large-format FFF (Fused Filament Fabrication) 3D printer engineered to handle the most demanding industrial designs. Featuring a massive 500 × 500 × 500 mm build volume and an actively heated thermal chamber that reaches 140°C, it creates a highly controlled environment that ensures exceptional part strength, accuracy, and warping-free results.

Designed with an advanced dual-extrusion printing system, the Omni PRO is a powerhouse for prototyping, end-use parts, and low-volume production runs.

View full specifications & features ↓

High-Temperature Engineering and Precision Manufacturing at Scale

Designed with an advanced dual-extrusion printing system, the Omni PRO is a powerhouse for prototyping, end-use parts, and low-volume production runs.

View full specifications & features ↓

Product Details

Engineered for High-Performance Materials: PEEK, PPA, PC, & More

Traditional 3D printers struggle with advanced engineering thermoplastics due to rapid cooling and warping. The Omni PRO features high-temperature heads (capable of reaching 500°C), a heated platform up to 180°C, and an actively heated chamber. This allows you to print smoothly with advanced materials, including:

PEEK, PPA, & Polycarbonate (PC) for high-strength, structural components.
CARBON/GLASS Fiber-reinforced filaments (using optional systems) for lightweight, ultra-rigid designs.
ULTEM & PPSU for extreme thermal and chemical resistance.

Technical Parameter

Omni PRO Specification

Print Technology	FFF (Fused Filament Fabrication)
Build Volume	500 × 500 × 500 mm
Layer Height	50 μm
Dimensional Accuracy	± 0.2% *
Print Speed	86 cm³/h
Slicing Software	Simplify3D
Supported Input Formats	.stl, .obj, .3mf, .gcode, .factory
Connectivity	SD card, Ethernet, Wi-Fi
User Interface	7” LCD touch screen
Power Supply	230 V / 50 Hz
Power Consumption	2.2 kW
Printer Dimensions	120 × 107 × 77 cm
Printer Weight	190 kg
Safety Certification	CE
Warranty	12 months

Choice of 4X Omni 3D Printers

OMNI 3D Printer	LITE	TECH	PRO	PRO HT
Build volume	460x460x560mm	500x500x570mm	500x500x500mm	500x500x500mm
Bed temp °C	150	170	180	220
Chamber temp °C	50	75	140	220
Extruder temp °C	260	360	500	500
Key Materials	PLA, TPU, PETG, Ceramic, Metal	ABS, ASA, PA, PSU, PP	PEEK, PPA, PC	ULTEM 1010, ULTEM 9085, PPSU

* Dimensional accuracy depends on whether the model has been appropriately scaled before printing it out – so as to compensate material shrinkage, model geometry, and layer height.
